的用途与简单/Brief Introduction：

本生产制造线由全自然理瓶机、全自然定频式双用数片（粒）机、自然定频式塞纸旋盖机、电滋感应开关铝箔纸密封机、双面标贴纸空气能机组成。应用在于制药业、保健食品、洗化用品等行业内的片状、丸剂、口服胶囊和其他异形3片的计数器装灌、塞纸、旋盖、密封、标贴纸等标签印刷工作全过程中。The production line consists of auto bottle unscrambler, automatic frequency variable counting machine, automatic frequency variable paper inserting & capping machine, electromagnetic induction aluminum foil sealing machine and vertical labeling machine. It is suitable for counting, filling, paper inserting, cap screwing, sealing and labeling whole packing process of troche, capsule, granule or other abnormal bottles in pharmacy, foodstuff and cosmetics and other field.

特质/Characteristic：

◆主动理瓶机，理瓶的过程 完全通过机舞蹈动作，不用专业人员安装监控，省时杠杆原理杠杆原理。Automatic bottleunscramble bottle unscrambled completely by mechanism, need not additional caretaker, save time and labor.◆直流交流变频筛动式数片机：轰鸣声小、落片增强、计算合理、快与慢快与慢实现直流交流变频还可以调控，并装是否瓶终止落片的光控系统.Counting machine: Low noise, counting accurate, speed adjusted by frequent inverter, no bottle no filling.◆定频式塞纸旋盖机：设定操作过程发达，成分合理的紧促，自功化送纸、一把剪刀中断 ，进程快与慢完成定频调压，无瓶自功化欠费。Paper inserting & capping machine: Advanced .principle, reasonable structure, automatic paper feed and cut, speed adjusted by frequency inverter, no bottle automatic stop sytem.◆铝箔纸纸塑封机：要配无铝箔纸纸全自动筛选安装，加速度在有一定领域内能自由调节Aluminum foil sealing machine: Automatically eliminate function for cap that has no aluminum foil, Speed can be adjusted in certain scope.◆透明不干胶标贴机：具备有无瓶时系统自行进行出标，系统自行打批号技能。 Labeling machine: no bottle no label feeding, automatic code typing.

技能技术指标/ Technical Parameters：

符合产品规格Bottle Range	15-500ml
出产值力 Productivity	30-60瓶/分 30-60bottles/min
24v电源Power Supply	380V/50Hz
功效 Total Power	4.5 kw
出产线总长Dimension	8000*900*1700mm
