主要用途与详细介绍/Brief Introduction：

远程服务器组为10-20ml服食液液滴装灌机械工作销售线中的重点机械。是由洗瓶、风干箱合二为一机和装灌机械密封合二为一机所构造，能重新完成任务服食液瓶的洗瓶、风干箱、装灌机械和密封等健身动作，是服食液工作销售服务商更佳的搭配机械，几乎适用GMP规定要求。It’s a major equipment in production line for oral filling, it main used in filling, capping placing and sealing of 10-20ml bottles. Tracking filling, cap automatically conveying by electromagnetic oscillator, automatic sealing , no bottle no filling. Filling and sealing integrated in one machine, advanced design, compact structure and completely comply with requirement of GMP

特征/Characteristic：

◆装量精确性，处理滴漏问题。装灌可靠性强，精密高。High filling accuracy.◆变频柜无及控速，种植线高速度可以调节，自选择多种的种植线高速度。Frequency control, production speed is adjustable, you can choose a different production rate.◆大多数小家电零件均通过进口的有名店牌。All electrical components are imported famous brands.◆自然显视筛选用途。Automatically countting function.◆操纵采取德国三凌PLC，抗扰乱，运行安全稳定。Controlled by Mitsubishi PLC◆能力稳定可靠，保障的保养省事。Stable performance, easy maintenance.◆整体外表面选用SUS304不锈铝制作而成、与货品碰触地方选用316L不透钢。整体是完全按GMP规范方案。Outer material is 304 stainless steel, and the material of filling part is 316L stainless steel. The machine is completely designed according to GMP requirements.

系统主要参数/technical parameters：

应用尺寸规格/Bottle size	10-20ml
产生业务能力/Capacity	60-90瓶/半个小时/60-90bottles/min
烘干设备室温/Dryer tempreture	100-300°
回收利用水访问量量/Water wastage	0.5m3/h
清洁水耗量/Purifying water consumption	0.3m3/h
装量精密度/Filling precision	≤1%
电压/Voltage	380V/50Hz
输出/Power	33KW
的生产流水线总长/Dimension	3500×1500×1600mm
