使用与筒介/Brief Introduction：

全自行齿轮泵式膏体酱罐安装系统而我工司适应环境市面 市场趋势设计的新设备。该设备利用SUS304不透钢齿轮泵式记量泵进行罐装，且集自行上盖、自行旋盖、机械电子商务为一体化，金钱实用型，土地征用空间小，普遍软件应用于药业有限公司、食品原料、农约、纸业、美妆品等企业的固体包裝，具有GMP规范了要。Automatic plunger paste paste filling machine is my company to meet the market demand, introduction of foreign advanced technology to develop new products. This machine adopts SUS304 stainless steel plunger metering pump filling, cover and set for automatic, automatic screw cap, integration of the mechanical and electrical, economical and practical, cover an area of an area small, widely used in pharmaceutical, food, pesticides, chemical industry, cosmetics and other industries of liquid packaging, full compliance with GMP requirements.

优势特点/characteristic：

◆应用轴向柱塞泵式测量泵制定灌装生产线，适宜各式稠状度溶剂，计算精度更高；泵的形式应用快接式拆御企业，有利于清洁工作、清洁消毒。Adopt plunger type metering pump filling, used various viscosity liquid, high precision; The structure of pump adopts fast disassembly institutions, easy cleaning and disinfection◆柱塞泵式计算泵缸筒环质量按照相关行业及粘液的成分的不一样所选择硅硅橡胶，四氟氯乙烯或另外质量，特有场景所选择瓷砖质量。Plunger metering pump piston ring material according to the industry and different adopt silicon rubber, liquid ingredients tetrafluoroethylene or other material, special occasions with ceramic material◆PLC掌控系统化，交流变频调速器，自動化成度高。PLC control system, frequency control of motor speed, a high degree of automation◆缺瓶不灌装设备，自动的筛选功能表。Lack of bottle filling, automatic counting function◆装量改变利于，可是次改变全压力容器检验检验泵的充填量，也可对各大压力容器检验检验泵完成微幅改变；控制简便计算，改变高速 。The load adjustment is convenient, can be a filling quantity of all pumps also can be slightly adjusted according to various metering pump; Simple operation, rapid adjustment◆分装针头设置有防漏滴安全装置，充填时潜进瓶底分装，速度慢提升，控制汽泡。Filling needles a drip-proof device, filling into the bottom of the bottle filling, slowly rising and prevent bubbles.◆机床可适用人群各不相同标准的小瓶，调整简单便捷，可在暂时性间内实现。The machine is suitable for various specifications of bottles, easy adjustment, it can be finished in a short period of time◆整个设备按GMP条件定制。The machine designed according to the requirements of GMP

高技术因素/technic parameter：

应用空瓶规模Size of bottles	20-1000ml（只能根据必须为您加工定制）20-10ౠ00 - ml (according to yo🔯ur need）
使用塑料瓶子直径约Apply the bottle diameter	¢20-¢150mm
用于盖子外形尺寸Apply the lid specifications	¢20-¢70mm
加工作用 production capacity	四头灌装线：1000-2500瓶/小时英文 Four filling head: 1000-2500 bottles per hour 八头装灌：2500-4000瓶/个钟头 Eight head filling: 2500-4000 bottles per hour 12头装罐：4000-6000瓶/小的时候 12 head filling: 4000-6000 bottles per hour
装量计算误差The load error	±1%
旋盖达标率Screw cover percent of pass	≥99%
电压power supply	380V，50HZ
最大功率power	3.0KW
安全阀gas sources	0.4-0.75MPA
速度快抑制speed control	直流变频空调变频调速variable speed
