主要用途与详细资料/Brief introduction:

机器是在引入和消化海外优秀技术水平的根基上，我装修公司自主经营研发部门的那款正规专业对口服药液和糖浆的灌装生产线、上塞、旋（轧）盖机。机器用到日本国全进口的高的精密度开放式式凸轮轴精确等级治具器，的精密度较高，加载可靠的，用生存期长。该精确等级器结构特征轻松，持久用不要维修费。该机关键支持于各种各样的口服方式液及糖浆体体的包装、压塞及旋（轧）盖，多用在保健食品、药业有限公司、化工环保产业及科学前沿技术。完全性具有中国GMP要。NFGX-30/100 Automatic Oral&sSyrup Filling&rotation (rolling) machine is built in the absorption of foreign advanced tecnology, based on independently developed by the company ,It is the domestic leading level.This machine is suitable for oral and syrup liquid filling&capping. Widely used in food, pharmaceutical, chemical industries and scientific research.Full compliance with the GMP requirements.

特殊性/Characteristic：

◆组队接面快速设置、的操作举例子不方便、PLC调整，装量*。Human-machine interface settings, an easy and intuitive, PLC control.◆调频设定、生产方式流速多个调整、自然计算。Frequency control, the production rate be adjusted automatically count. ◆自行停止用途，无瓶不装灌。No bottle no filling. ◆高保持精度轴承精度等级计保持，产品定位*。High-precision cam meter control, precise positioning◆通过SUS304及316L不锈钢材质的制作业，是合乎GMP符合要求。SUS304 and 316L stainless steel, full compliance with GMP requirements.

方法产品参数/ technical parameters：

装量区间Filling volume	30-150ML
装量确定误差loading error	≤ ±1%
旋（轧）盖完成率Rotation (rolling) Cover pass rate	≥99%
生产加工功能 Production capacity	30-60瓶/分 钟  底速 70-100瓶/分 钟     ඣ稳定 30-60 bottles / min  70-100 bottles / min
电原Power	380V/50Hz
工作电压Power	2.0 kw
系统重量Net weight	600 kg
外貌宽度Dimension	2000*1000*1500mm
